Configuring Code Composer Studio

Code Composer Studio needs to be configured for the hardware you have in your system. Clicking on the "Auto config" button will instruct the wizard to do this for you, based on the hardware modules specified earlier.

You may need to configure CCS manually if you have a non-standard configuration. Clicking on the "Manual config" button will open the CCS setup window where you can specify your configuration. For more information about how to configure CCS manually see the SMT6012 user manual.

For more information about JTAG click here.
