Embedded World 2023:


– Trenz Electronic TE0950 released

– New 2023 catalogue is now available.

Last week, at Embedded World, Trenz Electronic launched its first Evalboard with an AMD Versal™ AI Edge device. The TE0950 is a powerful adaptive SoC evaluation board, equipped with a large number of inputs and outputs.

Full details of the TE0950 can be found below or on the Trenz Electronic site here.

Trenz Electronic specialize in the design of high-speed data acquisition, high-accuracy measurement and embedded digital signal processing systems based on FPGA and CPU architectures.

Many of their products are compatible with some widespread form factors. They also provide SoM products for the Automotive industry and high-end applications.

We are the UK distributor for their products. You can download the NEW 2023 catalogue in PDF form or browse through it at the bottom of this page. COntact us with any requirements!


TE0950 AMD Versal™ AI Edge Evalboard with VE2302 device


The Trenz Electronic TE0950-01-EGBE11A is a powerful adaptive SoC evaluation board, equipped with an AMD Versal™ AI Edge VE2302 device (engineering sample). Furthermore, the board is equipped with 4 GByte DDR4 SDRAM and 128 MByte SPI Flash for configuration and data storage as well as powerful switching power supplies for all required voltages. A large number of inputs and outputs are provided by robust, flexible and cost-effective high-speed connectors.

All parts are at least commercial temperature range of 0°C to +70°C. The module operating temperature range depends on customer design and cooling solution. Please contact us for options.

Key Features

  • SoC
    • AMD Versal™ AI Edge XCVE2302-1LSESFVA784 device (engineering sample)
      • A784 package (pin compatible VE2002, VE2102, VE2202, VE2302, VM1102)
  • RAM/Storage
    • 4 GByte DDR4 SDRAM
    • 128 MByte SPI Flash (primary boot option)
    • MicroSD card (primary boot option)
    • 32 GByte e.MMC (secondary boot option)
    • EEPROM with MAC-address
  • On Board
    • AMD Artix™ 7 FPGA as configurable Levelshifter/MUX for FMC and other 3.3 V IOs
      • 32 MByte SPI Flash
      • 1 dip switch
      • 2 LEDs
    • USB 2.0 Host/Device/OTG (type Micro A/B connector)
    • USB JTAG + UART Micro-USB B
    • Gigabit Ethernet RJ45
    • Output
      • 2 LEDs (1 x MIO, 1 x PL)
    • Input
      • 1 push button
      • 3 dip switches (2 x MIO, 1 x PL)
      • Reset button
  • Interface
    • zQSFP with 4 GTYP Transceiver
    • 2 x CRUVI HS (each optimized for 4 Lane MIPI, one with reduced pinout)
    • 2 x CRUVI LS
    • CSI-2 connector (camera, 2 lane MIPI)
    • FMC
      • 4 GTYP Transceiver
      • 34 LA diff pairs to Levelshifter/MUX
  • Power
    • 12 V plug
  • Dimension
    • 150 mm x 120 mm

Trenz Electronic catalogue 2023
