NOT FOR NEW DESIGNS
Features
- Single width TIM
- 167MHz C6701 Floating Point DSP
- 1GFLOPS peak performance
- 16Mbyte high speed SDRAM
- 512Kbyte SBSRAM
- TIM Global Connector
- Two 200Mbytes/s SDB Interface ports
- Six ComPorts up to 20Mbytes/s each
- 512Kbytes FLASH ROM for configuration/booting
- JTAG Diagnostics Port
- 12 months warranty
- Weight Approx. 58g
Benefits
Simple implementation of multi-processor solutions
Scaleable system architecture
Balanced Communications/processing resources
Flexible interface strategies with range of I/O methods
Large range of COTS peripheral items such as ADC, DAC, FPGA
Compatible with C6201 variants
Applications
Multiprocessor DSP systems
Multi Channel Telecommunication systems
Cellular Base Station Development
Algorithm Prototyping
Image Processing
Military Signal processing
Software Support
3L Diamond RTOS Compiler
Sample Source Code
